Schneider Charge 充電站，1P+N，附帶 7 米電纜，7.4kW，32A
操作簡便 – 充電不中斷日常生活，維持家居電力系統正常運作
快速充電 – 縮短充電時間
可持續性 – 配合 Wiser 排程功能，優先使用再生能源進行充電
成本效益高 – Wiser 可讓您選擇避開尖峰電價的最佳充電時段，並配合使用再生能源
安心無憂 – 全球客戶服務支援

此款 Schneider Charge 產品是一款壁掛式充電站，適用於所有符合 IEC61851-1 標準的電動車。其防水防塵等級為 IP55，抗衝擊等級為 IK10。操作溫度範圍為 -35°C 至 50°C。輸出端為 7 米附帶電纜，末端為 T2 插座，安裝於充電站底部與頂部中央。額定輸出功率為 7.4kW。電源為單相（1P+N），充電電流為 32A，電壓為 230VAC，頻率為 50Hz/60Hz。可配合 TN-S、TT 或 IT 接地系統使用。
安裝簡單，無需特殊工具，適合於家庭私人用途，可安裝於車庫內牆面或戶外牆面。產品尺寸為寬 244mm x 高 352mm x 深 107mm。產品重量為 5.3kg（不含電纜）。產品顏色為白色（RAL 9003）及綠色。內建直流剩餘電流偵測保護裝置（RDC-DD）。本產品無使用限制控制，任何人可使用該充電站為電動車充電。LED 燈可變換紅、綠、藍顏色，以即時顯示充電狀態。
本充電站能即時調整分配給電動車的最大充電功率，依據家中其他設備的用電情況，並依據 TIC 傳送的尖峰／離峰時段調整充電負載。充電站可透過 Schneider Electric™ 的 Wiser 手機應用程式連接，實現住宅能源管理，輕鬆啟動、監控並遠端控制整個充電體驗。
本產品支援 OCPP 1.6 通訊協定，可連接監控設備或第三方雲端平台，也可透過 Wi-Fi 或 RJ45 網線連接家庭路由器上網。

Charging station, Schneider Charge, 1P+N, attached cable 7m, 7.4kW, 32A
User friendly – Charge your car without disrupting your lifestyle, keeping your installation running as needed
Fast – Speed-up your charging duration
Sustainable – Charge your car prioritizing renewable energy thanks to Wiser scheduling function
Cost efficient – Wiser enable to choose right time to charge avoiding peak tariffs and using renewable energy
Peace of mind - Worldwide customer care center

Charging station, Schneider Charge, 1P+N, attached cable 7m, 7.4kW, 32A User friendly – Charge your car without disrupting your lifestyle, keeping your installation running as needed Fast – Speed-up your charging duration Sustainable – Charge your car prioritizing renewable energy thanks to Wiser scheduling function Cost efficient – Wiser enable to choose right time to charge avoiding peak tariffs and using renewable energy Peace of mind - Worldwide customer care center This Schneider Charge product is a wall-mounted charging station for all electrical vehicles compliant with IEC61851-1 standard. The IP degree of protection is IP55. The IK degree of protection is IK10. The operating temperature is between -35°C and 50°C. The output type is a 7m attached cable with a T2 socket-outlet at the end, installed at the bottom and top centre of the station. The nominal output power is 7.4kW. It is supplied in single-phase (1P+N). The rated charging current is 32A under 230VAC at 50Hz/60Hz frequency. It can be used with a TN-S, TT or IT earthing system. The charging station is easy to install (no special tools required). It is recommended for private use at home, installed in the garage or on a wall externally. The dimensions are (W) 244mm x (H) 352mm x (D) 107mm. Its product weight is 5.3kg (without cable). Its color is white (RAL 9003) and green. It is fitted with a built-in protection against residual direct current (RDC-DD as Residual Direct Current Detecting Device). There is no access control to use the charging station for loading an electrical vehicle. One LED is changing color between red, green and blue in order to indicate the loading status directly on the charging station. This one allows to adjust in real time the maximum power allocated to the charging electric vehicle, according to the consumption of the rest of loads in the house and adapt the load according to Off Peak/Peak hours sent by TIC. The charging station is connected with Wiser by the Schneider ElectricTM mobile application for residential energy management. It easily starts, monitors, and controls the charging experience remotely. The OCPP 1.6 communication protocol can be used to connect to the supervision device/third party cloud. It can also be connected to Internet home router, either through Wi-Fi or RJ45 Ethernet cable.
