EVlink Pro AC/AC 金屬款充電站，22kW，32A，3P+N，T2S 插座，內建 RCD B-EV 與 MNx 附屬裝置
可靠： 符合最新 IEC 61851 第三版與 OCPP 1.6 Json 標準
堅固： IP55 防水防塵等級與 IK10 抗衝擊等級，另有金屬外殼版本可選
未來就緒： 可升級安裝 4G、Wi-Fi、ISO15118 模組
靈活模組化、維護成本低
輕鬆設定： 可使用 eSetup 應用程式進行安裝設定

此款 EVlink Pro AC 是一款適用於所有符合 IEC61851-1 標準的電動車之壁掛式充電站，也可選擇落地式安裝，需另購專用底座或安裝套件。可於室內或戶外使用，具備 IP55 防護等級及 IK10 抗衝擊等級，適用於 -30°C 至 50°C 操作溫度範圍，儲存溫度為 -40°C 至 80°C。
輸出端為前置 T2S（帶保護蓋）插座，所有接點為鍍銀處理，有效防止過熱。額定輸出功率為 22kW，三相供電（3P+N），充電電流為 32A，電壓範圍 380V–415VAC，頻率 50Hz–60Hz。支援 TT、TN-S、TN-C-S 接地系統，如使用 IT 系統則需另接隔離變壓器。
本產品安裝簡易，推薦用於家庭、車隊、街道或辦公場所。尺寸為 (寬)317mm × (高)529mm × (深)153mm，淨重 7.2kg，顏色為白色 (RAL9003)。內建 B-EV 類型直流漏電保護裝置（RCD）與 MNx 欠壓跳脫附屬裝置，符合 EV Ready 要求。
可從機背、頂部或底部接入電源線。支援 RFID 或 NFC 卡進行使用者驗證，也可設為無需驗證的自由存取模式。支援延遲啟動，並可根據整體電力狀況進行充電功率限制，以維持穩定供電並最佳化多台設備的充電效率。
設備具備 2 個 RJ45 網絡接口，透過 eSetup App（藍牙連接）或 EcoStruxure EV Charging Expert 進行參數設定，可單機使用或多台聯網管理。支援 OCPP 1.6 通訊協議以連接監控平台，提供充電紀錄、故障診斷與負載管理功能。通過 CE 及 EV Ready 認證，並保證在停產後兩年內持續提供韌體更新維護。

Charging station, EVlink Pro AC/AC Metal, 22kW, 32A, 3P+N, T2S socket-outlet, RCD B-EV, MNx aux.
Reliable: Conforms with latest IEC 61851 ed.3 and OCPP 1.6 Json
Robust: IK10 and IP55, also available in metal enclosure
Future ready: Upgradeable with 4G, Wi-Fi, ISO15118 modules
Flexible, modular, and low maintenance
Easy commissioning with eSetup app

This EVlink Pro AC product is a wall-mounted charging station for all electrical vehicles compliant with IEC61851-1 standard. It can also be floor-standing, either fixed on a pedestal, or integrated in a kit enclosure. Both pedestal or kit enclosure have to be ordered separately. It can be installed indoor as well as outdoor. The IP degree of protection is IP55. The IK degree of protection is IK10. The operating temperature is between -30°C and 50°C. The storage temperature is between -40°C and 80°C. The output type is a T2 socket-outlet with shutter (T2S), fixed on the front face of the station. All the contacts of T2S socket-outlet are silver-plated avoiding overheating. The nominal output power is 22kW. It is supplied in three-phase (3P+N). The rated charging current is 32A under 380V to 415VAC with a 50Hz to 60Hz frequency. It can be used with a TT, TN-S, or TN-C-S earthing system. It is also IT compatible with an additional isolation transformer on the power supply. The charging station is easy to install and to comission. It is recommended at home as well as at fleets, at street or at work. The dimensions are (W) 317mm x (H) 529mm x (D) 153mm. Its product weight is 7.2kg. Its color is white (RAL9003). It embeds a built-in protection against residual direct current, with a B-EV (Electric Vehicle) type residual current device (RCD). An MNx under voltage tripping auxiliary is also integrated in the charging station for safety. Moreover, it is necessary to meet EV Ready requirements. The charging station can be fed by cable coming from the rear, the top or the bottom of it. To load an electrical vehicle, the access control is done by a user authentication through RFID or NFC badge. But the charging station can also be used for free access. The load starting can be time-delayed. During the load time, the power can be limited to ensure the continuity of service and optimize the charging time of all the charging station based on a same feeding. It has 2 Ethernet RJ45 ports for LAN connection. The parameters are set up through eSetup app via Bluetooth or EcoStruxure EV Charging Expert. The charging station can be managed in standalone or in clustered architecture. The OCCP 1.6 communication protocol is used to connect to the supervision device.The available services are the charge detail records, the diagnosis capabilities and the load management. The charging station has the CE and EV Ready certification. The firmware of EVlink Pro AC is maintained until 2 years after the end of commercialisation.
